Specifications: 1.dia.of the stepcone for finished wire:260mm 2.number of wiredrawing dies:10 3.dia.of feeding wire:8mm 4.dia.of output wire:3.74mm 5.cumulative reduction:78% 6.mean pass reduction:14% 7.drawing speed:46m/min 8.associated motor:Y180L-6-15kw 9.overall dimension(LxWxH):2200x1020x1150mm 10.weight:2500kg Type: LT-20/293
Specifications: 1.dia.of the stepcone for finished wire:293mm 2.number of wiredrawing dies:20 3.dia.of feeding wire:5mm 4.dia.of output wire:1.6mm 5.cumulative reduction:90% 6.mean pass reduction:10.7% 7.drawing speed:120m/min 8.associated motor:YCT200-4-7.5kw 9.overall dimension(LxWxH):2000x1020x1100mm 10.weight:2000kg
