1.dia.of the spool:630mm
2.dia.of taken-up wire:1.5mm, 3mm
3.max.taking-up speed: 600m/min
4.way of line-arranging: with a polish shaft
5.pitch of line-arranging:1-40mm
6.max.push of line-arranging:pitch of line-arranging:40N
7.associated motor:YLJ160-40-4
8.dimension of the spool (LxWxH):630*300*350mm
9.weight of a bundle:300-500kg
10.Overall dimension(LxWxH):1250x1200x1000mm
11.Weight:900kg
