1.dia.of the speed lock wheel:f315mm
2.quantity of dies:9
3.dia.of a feeding wire:1.7mm
4.dia.the output wires:1.12×1.12mm, the minimum:0.35×0.35mm
5.cumulative reduction:85%
6.mean reduction ratio:20%
7.drawing speed:300-800m/min
8.associated motor (frequency control):YCT-160-4-11kw
9.external diemnsion:1500×1000×1000mm (L*W*H)
10.weight:1500kgension device,f400 spool coiler,mainly used to draw shaped brass wires.
